Cylinder Block Specifications
WARNING: This page is about a different car, the 1992 Geo Metro, 1991 Geo Metro, and 1990 Geo Metro. However, it is still accessible from the selected car via links, so may be relevant.
CYLINDER BLOCK SPECIFICATIONS
| Application | In. (mm) | ||||
|---|---|---|---|---|---|
| Cylinder Bore | |||||
| Standard Diameter (1) | |||||
| No. 1 | 2.9138-2.9142 (74.011-74.021) | ||||
| No. 2 | 2.9134-2.9138 (74.000-74.011) | ||||
| Maximum Taper | .0039 (.099) | ||||
| Maximum Out-of-Round | .0039 (.099) | ||||
| Maximum Deck Warpage | .0024 (.061) | ||||
|
|||||
