Vehicle Certification, Tire Placard, Anti-Theft and Service Parts ID Label

WARNING: This page is about a different car, the 2007 Suzuki XL7. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Vehicle Certification, Tire Placard, Anti-Theft & Service Parts ID Label

Courtesy of SUZUKI OF AMERICA CORP.

VEHICLE CERTIFICATION, TIRE PLACARD, ANTI-THEFT AND SERVICE PARTS ID LABEL SPECIFICATION

Callout	Description
Vehicle Certification Label The vehicle certification label is located on the driver door and displays the following assessments: Gross vehicle weight rating (GVWR) Gross axle weight rating (GAWR), front and rear The gross vehicle weight (GVW) is the weight of the vehicle and everything it carries. The GVW must not exceed the GVWR. Include the following items when figuring the GVW: The base vehicle weight (factory weight) The weight of all vehicle accessories The weight of the driver and the passengers The weight of the cargo
1	Name of Manufacturer
2	Gross Vehicle Weight Rating
3	Gross Axle Weight Rating (Front, Rear)
4	Canadian Safety Mark (w/RPO Z49)
5	Certification Statement
6	Vehicle Class Type (Pass Car, etc.)
7	Vehicle Identification Number
8	Date of Manufacture (Mo/Yr)
Tire Placard The tire placard label is located on the center pillar and displays the following assessments:
9	Specified Occupant Seating Positions
10	Maximum Vehicle Capacity Weight
11	Original Equipment Tires Size
12	Tire Pressure, Front, Rear, and Spare (Cold)
Service Parts ID Label The vehicle service parts identification label is located in the instrument panel (I/P) compartment. The label is use to help identify the vehicle original parts and options.
13	Model Designation
14	Order Number
15	Exterior Color
16	Paint Technology
17	Vehicle Identification Number
18	Wheel Base
19	Part Number Location
Anti-Theft Label
20	The Federal law requires that manufacturer label certain body parts on this vehicle with the VIN. The purpose of the law is to reduce the number of motor vehicle thefts by helping in the tracing and recovery of parts from stolen vehicles. Labels are permanently affixed to an interior surface of the part. The label on the replacement part contains the letter R, the manufacturer's logo, and the DOT symbol. The anti-theft label must be covered before any painting, and rustproof procedures, and uncovered after the procedures. Failure to follow the precautionary steps may result in liability for violation of the Federal Vehicle Theft Prevention Standard and possible suspicion to the owner that the part was stolen.
