Oil Pump

NOTE: The illustration for 2.5 L Non-TURBO model is shown below. (Not shown for TURBO model and 3.0 L mod because it cannot be disassembled.)

Fig 1: Exploded View Of Oil Pump Components With Torque Specifications

Courtesy of SUBARU OF AMERICA, INC.
