Side Retainer

WARNING: This page is about a different variant/trim than selected.
  1. Remove O-ring.
    Fig 1: Removing O-Ring
    G02876487Courtesy of SUBARU OF AMERICA, INC.
  2. Remove oil seal.
Fig 2: Removing Oil Seal
G02876488Courtesy of SUBARU OF AMERICA, INC.
