Stop/Tail/Back-Up/Turn Marker Lamp Inline (2ND Design)

Fig 1: Stop/Tail/Back-Up/Turn Marker Lamp Inline (2nd Design) - 5-Pin Connector (12146045) - Natural
G00174230Courtesy of GENERAL MOTORS CORP.
