Fuel Pipe Shield Replacement

Fig 1: Identifying Fuel Pipe Shield, Push-Pin And Fastener

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Callout	Component Name
Preliminary Procedures
Remove the intake manifold cover. Refer to INTAKE MANIFOLD COVER REPLACEMENT .
1	Fuel Pipe Shield Fastener Refer to CAUTION: RETAINER Tighten 9 N m (80 lb in)
2	Fuel Pipe Shield Push-Pin
3	Fuel Pipe Shield
