To remove

  1. Remove the selector lever housing, see SELECTOR LEVER HOUSING .
    IMPORTANT: When working on a dismantled selector lever housing, the selector lever should be protected with foam rubber or the like.
  2. Remove the ignition switch connector.
    3. Fig 1: Removing Ignition Switch Connector
    G03464137Courtesy of SAAB-SCANIA OF AMERICA, INC.
