Cupholder Replacement

Fig 1: Cupholder
GM1581741Courtesy of GENERAL MOTORS CORP.
Cupholder Replacement

Callout Component Name
Fastener Tightening Specifications:  Refer to Fastener Tightening Specifications .
Preliminary Procedure:
Remove the instrument panel assist handle bezel. Refer to Instrument Panel (I/P) Assist Handle Replacement .
1 Cup Holder Assembly, Instrument Panel
Tip:  Use a small flat-bladed tool to release the retaining tabs through the opening where the assist handle bezel was removed.
