Installation Procedure

    Fig 1: Removing Rear Seat Belt Anchor (Sedan)
    GM1233221Courtesy of GENERAL MOTORS CORP.
  1. Install the seat belt retractor to the vehicle.
    2. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the fastener to the seat belt retractor.

    Tighten:  Tighten the fastener to 35 N.m (25 lb ft).

  3. Install the seat belt anchor.

    Tighten:  Tighten the fastener to 35 N.m (25 lb ft).

  4. Install the rear window trim panel. Refer to Trim Panel Replacement - Rear Window Shelf in Interior Trim.
  5. Install the rear seat back assembly. Refer to Seat Back Replacement - Rear Split Folding in Seats.
