Removal Procedure

WARNING: This page is about a different car, the 2004 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the front door.
  2. Remove the carpet retainers. Refer to Carpet Retainer Replacement - Front in Interior Trim.
  3. Remove the weatherstrip by pulling it off the pinch-weld flange.
    4. Fig 1: Front Door Weatherstrip & Pinch-Weld Flange
    GM308132Courtesy of GENERAL MOTORS CORP.
  4. Remove the weatherstrip from the door opening.
