Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Position the liftgate window struts to the liftgate window.
  2. Install the lower end of the liftgate window struts to the ball joint. Press in to place until fully seated.
  3. Install the new hinge pin to the upper end of the liftgate window strut.
  4. Install the new retainer to the hinge pin.
  5. Remove the support from the liftgate window.
  6. Close the liftgate window.
    Fig 1: New Hinge Pin
    G01478240Courtesy of GENERAL MOTORS CORP.
