Inspection After Assembly

WARNING: This page is about a different car, the 2005 Infiniti FX45 and 2005 Infiniti FX35. However, it is still accessible from the selected car via links, so may be relevant.

With wheel bearing pressed into axle housing, apply 49,033 N (5,000 kg, 11,000 lb) to wheel hub and rotate both clockwise and counterclockwise 10 times to minimize resistance.
Attach spring scale in the position shown in illustration and pull at a rate of 10 +/- 2 rpm to measure rotating torque.
1. Rotating torque:
  1. Less than 2.7 N.m (0.28 kg-m, 24 in-lb)
2. Spring scale reading:
  1. Less than 26.6 N (2.7 kg, 5.95 lb)
Fig 1: Measuring Rotating Torque
Courtesy of NISSAN MOTOR CO., U.S.A.
