Section 1312 (Tire & Wheel): Repair

WARNING: This page is about a different car, the 2004 Lexus ES 330. However, it is still accessible from the selected car via links, so may be relevant.

VEHICLE PULLING DIAGNOSIS
1. Diagnosis of tire vibration

  Fig 1: Diagnosis Of Tire Vibration Flow Chart
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Diagnosis of premature or irregular tire wear

  Fig 2: Diagnosis Of Premature Or Irregular Tire Wear Flow Chart
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
