With Consult-II

WARNING: This page is about a different car, the 2004 Nissan Murano. However, it is still accessible from the selected car via links, so may be relevant.
  1. Turn ignition switch ON. (Do not start engine.)
  2. Select "DATA MONITOR" mode for "TRANSMISSION" with CONSULT-II.
  3. In fully depressed and fully released conditions, wait for 5 seconds.
  4. If DTC is detected, go to "DIAGNOSTIC PROCEDURE ".
    Fig 1: DATA MONITOR - Consult II Display
    G00769757Courtesy of NISSAN MOTOR CO., U.S.A.
