Special Tools
SPECIAL TOOLS DESCRIPTION
| TOOL | TOOL NUMBER AND NAME | SUPERSESSION | APPLICATION |
|---|---|---|---|
| MB990935 Installer adapter |
MB990935-01 or General service tool | Installation of output shaft taper roller bearing outer race and center differential rear taper roller bearing outer race | |
| MB990938 Handle |
MB990938-01 | Use with Installer adapter | |
| MD998801 Bearing remover |
MD998348-01 or General service tool | Installation and removal of gears, bearings and sleeves | |
| MD998812 Installer cap |
General service tool | Use with Installer and Installer adapter | |
| MD998813 Installer-100 |
General service tool | Use with Installer cap and Installer adapter | |
| MD998818 Installer adapter (38) |
MD998818 | Installation of input shaft front bearing | |
| MD998825 Installer adapter (52) |
General service tool | Installation of 1st speed gear sleeve, 3rd-4th speed synchronizer hub, 4th speed gear sleeve, 5th speed gear and thrust plate stopper | |
| MD998819 Installer adapter (40) |
General service tool | Installation of input shaft rear bearing and output shaft taper roller bearing | |
| MD998917 Bearing remover |
General service tool | Installation and removal of gears, bearing and sleeves | |
| MD998814 Installer-200 |
MIT304180 | Use with Installer cap and Installer adapter | |
| MD998824 Installer adapter (50) |
General service tool | Installation of 1st-2nd speed synchronizer hub, 1st speed gear sleeve, 2nd speed gear sleeve and 3rd speed gear | |
| MD998364 Camshaft oil seal installer |
MD998364-01 | Installation of gear, bearing and sleeve | |
| MD998821 Installer adapter (44) |
MD998821 | Installation of 4th speed gear, 5th speed gear sleeve and 5th-reverse speed synchronizer hub | |
| MD998820 Installer adapter (42) |
MIT215013 | Installation of reverse gear bearing sleeve | |
| MD999566 Claw |
General service tool | Removal of taper roller bearing outer race | |
| MB991445 Bushing remover and installer base |
MB991445 | Installation of differential front taper roller bearing outer race | |
| MB990928 Installer adapter |
MB990928-01 | Installation of input shaft oil seal | |
| MD998800 Oil seal installer |
General service tool | Installation of differential oil seal and transfer oil seal | |
| MB990930 Installer adapter |
MB990930-01 | Removal of center differential front taper roller bearing | |
| MB990937 Installer adapter |
MB990937 or General service tool | Installation of center differential front taper roller bearing and transfer oil seal | |
| MD998823 Installer adapter (48) |
General service tool | Installation of center differential rear taper roller bearing | |
| MD999506 Crankshaft installer |
- | Installation of transfer oil seal | |
| MB990936 Installer adapter |
MB990936-01 or General service tool | Installation of transfer oil seal |
