Scan Tool Or Voltmeter

If a problem is found in the Pulse Check, observe the table below.

Fig 1: Identifying Scan Tool Or Voltmeter Defects
G02324163Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
