Minimum Set: Mechanical Tools

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2005 BMW 545i, 2005 BMW 530i, 2005 BMW 525i, 2004 BMW 545i, and 2004 BMW 530i. However, it is still accessible from the selected car via links, so may be relevant.

Note: For evenly pressing down camshaft (with bearing cap) while releasing and tightening camshaft bearing caps

Engine: M42, M50, M52, M52TU, M54, M56, S50US, S52US

SI number: 1 05 89(099)

Order number: 11 3 260

Fig 1: Identifying Fixture

Courtesy of BMW OF NORTH AMERICA, INC.

Fixture

Consisting of:

1 = 11 3 261 Assembly fixture

2 = 11 3 262 Fastener bolt (2)
