Low/Reverse Piston: Disassembly

  1. Remove and discard the low/reverse clutch piston outer seal on the low/reverse clutch piston.
    Fig 1: Identifying Low/Reverse Clutch Piston Outer Seal
    G02164650
  2. Remove and discard the low/reverse clutch piston inner seal on the low/reverse clutch piston.
Fig 2: Identifying Low/Reverse Clutch Piston Inner Seal
G02164651
