Connecting Rod - Piston Pin Side Clearance

WARNING: This page is about a different car, the 2004 Ford RV Cutaway, 2004 Ford Econoline, and 2004 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.

Measure the clearance between the connecting rod and the piston. Verify the measurement is within specification.
- Refer to the appropriate ENGINE MECHANICAL article for the procedure.
- If out of specification, install new components as necessary. Refer to the appropriate ENGINE MECHANICAL article for the procedure.
Fig 1: Measuring Clearance Between Connecting Rod And Piston
Courtesy of FORD MOTOR CO.
