No. 1 Keyless Entry System Does Not Operate Normally [Keyless Entry System]: Notes
- When performing an asterisked (*) troubleshooting inspection, slightly shake the wiring harness and connectors while performing the inspection to discover whether poor contact points are the cause of any intermittent malfunctions. If there is a problem, verify that the connectors, terminals and wiring harnesses are connected correctly and undamaged.
DESCRIPTION AND POSSIBLE CAUSE
| 1 |
Keyless entry system does not operate normally |
| DESCRIPTION |
- Malfunction in door lock linkage system, or BCM
|
| POSSIBLE CAUSE |
- Malfunction in BCM power supply
- Open circuit in IG1 and/or B+ power supply circuit
- Open or short circuit in ground circuit
- BCM malfunction
- Malfunction in key reminder switch related circuit
- key reminder switch malfunction
- Malfunction in door latch switch signal circuit
- Open or short circuit in wiring between BCM and door latch switch
- Door latch switch malfunction
- Malfunction in door lock/unlock signal circuit
- Door lock actuator malfunction
- Open or short circuit in wiring between BCM and door lock actuator
- Malfunction in turn light signal circuit
- BCM malfunction
- Open or short circuit wiring between BCM and each turn signal light
|
 Courtesy of MAZDA MOTORS CORP.
|
