Special Tools - Steering
SPECIAL TOOLS CHART
| Mazda Required Tools | |
|---|---|
| Puller Remover tool 211-009 (T65P-3A733-C) |
|
| Pulley Replacer tool 211-185 (T91P-3A733-A) |
SPECIAL TOOLS CHART
| Tools or equivalent | |
|---|---|
| Teflon® Seal Replacer Set 211-D027 (D90P-3517-A) |
|
| Differential Bearing Remover 205-116 T77F-4220-B1 |
|
| Remover, Tie Rod End 211-001 (TOOL-3290-D) |
|
| Inner Tie-Rod Socket Tool 211-D029 or equivalent |
|
| Boot Clamp Pliers 205-D067 (or equivalent (D87P-1098-A) or equivalent |
|
| Spring Scale 211-034 (T74P-3504-Y) |
|
| Power Steering Analyzer 211-F001 (014-00207) |
|
| Vacuum Pump Kit 416-D002 (D95L-7559-A) or equivalent |
|
| Evacuation Cap, Power Steering 211-265 or equivalent |
|
| Fill Adapter Manifold, Power Steering 211-327 or equivalent |
