Automatic Transaxle [AW6A-EL]

AUTOMATIC TRANSAXLE [AW6A-EL]

AUTOMATIC TRANSAXLE [AW6A-EL]:





Flexplate bolts





Tighten the new drive plate mounting bolts in two or three steps in the order shown
Tightening torque 73 - 87 Nm (7.4 - 8.9 kgf-m, 54 - 64 ft. lbs.)

Control valve body cover bolts 9.8 - 15.7 Nm (100 - 160 kgf-cm, 87 - 138 inch lbs.)
