Air Flow Meter/Sensor: Service and Repair

MASS AIR FLOW (MAF) SENSOR

Removal and Installation

Mass Air Flow (MAF) Sensor:

1. Remove the air cleaner outlet tube. See AIR CLEANER OUTLET PIPE.
2. Disconnect the mass air flow (MAF) sensor electrical connector.
3. Remove the four nuts and the MAF sensor.
4. To install, reverse the removal procedure.
