Without Cruise Control System
- Disconnect the negative battery cable.
- Remove the fuse block cover.
- Remove the panel light control switch. (See PANEL LIGHT CONTROL SWITCH REMOVAL/INSTALLATION .)
- Push the tabs of the cruise control main switch and pull the switch out from inside of the dashboard.
- Disconnect the cruise control main switch connector to remove the cruise control main switch.
- Install in the reverse order of removal.
Courtesy of MAZDA MOTORS CORP.
