Intake-Air System Removal/Installation: Notes
WARNING:
- When the engine and intake-air system are hot, they can badly burn. Turn off the engine and wait until they are cool before removing or installing the intake-air system.
- Disconnect the negative battery cable.
- Drain the engine coolant from radiator. See COOLING SYSTEM .
- Remove in the order indicated in Fig 1.
- Install in the reverse order of removal.
- Refill the radiator with engine coolant. See COOLING SYSTEM .
