Fuse Panel Identification (Wagon Models): Notes

NOTE: Fusible links for the headlight & high beam indicator light as well as the alternator & regulator are located near the ignition coil on all models.
Fig 1: Fuse Panel Identification (Wagon Models)
G93F45372Courtesy of MAZDA MOTOR OF AMERICA, INC.
