Axle Ratio & Identification
All Mazda models use one basic type of rear axle assembly. Any differences in Removal & Installation or Overhaul procedures will be noted where they occur.
Axle ratio on GLC Wagon (automatic), B2200 Pickup and RX7 is 3.909:1. B2000 Pickup is 3.307:1 and GLC Wagon (manual) is 3.727:1. To determine axle ratio, divide number of ring gear teeth by number of pinion teeth.
