HVAC Module-Vehicles With Electronic Automatic Temperature Control or Electronic Manual Temperature Control Remote Mount

WARNING: This page is about a different car, the 2013 Ford F-550 Super Duty, 2013 Ford F-450 Super Duty, 2013 Ford F-350 Super Duty, and 2013 Ford F-250 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.
G08599315
Item Part Number Description
1 W707628 HVAC module screw (4 required)
2 19980 HVAC module
  - HVAC module electrical connectors (2 required) (part of 14401)
