Rain Sensor: Service and Repair

Rain Sensor

1. Remove the Headlamp Control Module 2 (HCM-2).

2. NOTE: Prior to releasing the rain sensor retaining clips, it is necessary to apply light inward pressure at the bend of the retaining clips.

Release the 2 rain sensor retaining clips and remove the rain sensor.





3. To install, reverse the removal procedure.
- Prior to installing the rain sensor, the windshield glass area of the rain sensor must be cleaned.
