System Specifications

Timing Gear
Tighten the bolts in two stages:
1: Tighten 40 Nm (30 ft. lbs.)
2: Tighten additional 90 degrees.








Engine front cover
Tighten the bolts in the sequence shown in three stages:
1: Tighten 2 Nm (18 inch lbs.).
2: Tighten 20 Nm (15 ft. lbs.).
3: Tighten an additional 60 degrees.

Timing Chain and Tensioners
Timing Chain Tensioner
