Installation

PARKING BRAKE: ELECTRIC PARKING BRAKE ECU: INSTALLATION

1. INSTALL ELECTRIC PARKING BRAKE ECU

(a) Install the parking brake ECU with the 2 nuts.





Torque : 8.0 Nm (82 kgf-cm, 71 in-lbf)

(b) Connect the 2 connectors.

(c) Install the seat belt control ECU with the 2 nuts.





Torque : 5.5 Nm (56 kgf-cm, 49 in-lbf)

(d) Connect the 2 connectors.

2. INSTALL LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH Installation

3. INSTALL DECK TRIM SIDE BOARD LH Installation

4. INSTALL REAR FLOOR FINISH PLATE Installation

5. INSTALL LUGGAGE COMPARTMENT MAT SUB-ASSEMBLY Installation

6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

7. INSTALL COWL TOP VENTILATOR LOUVER RH Installation

8. PERFORM INITIALIZATION

(a) Perform initialization Repair Instruction - Initialization.

NOTICE:
Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

9. PERFORM CALIBRATION

(a) Clear the electric parking brake ECU memory and acquire tension sensor zero point Programming and Relearning.
