Monitor Result

Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .

Fig 1: Checking Monitor Status Displayed On Tester
GTY129419Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
