CRUISE CONTROL: LASER SENSOR: REMOVAL

REMOVAL

1. REMOVE ENGINE UNDER COVER NO.1 Removal
2. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY RH Removal
3. REMOVE FRONT FENDER SPLASH SHIELD SUB-ASSEMBLY LH Removal
4. REMOVE FRONT BUMPER COVER Removal
5. REMOVE FRONT BUMPER ENERGY ABSORBER
6. REMOVE FRONT BUMPER REINFORCEMENT [1][2]Disassembly
7. REMOVE LASER SENSOR





(a) Disconnect the connector and remove the laser sensor.
