Shift Solenoid Valve: Components

Fig 1: Exploded View Of Shift Solenoid Valve With Torque Specifications (1 Of 2)
G05318002Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Exploded View Of Shift Solenoid Valve With Torque Specifications(2 Of 2)
G05317594Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
