Circuit Diagram
>>
[Driver/Passenger Safety]
September 30: LEMON manuals is back up on a temporary server! Slowness is possible
[Driver/Passenger Safety]
Fig 1: Driver/Passenger Safety Circuit Diagram
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
