Home >> Kia >> 2009 >> Rondo LX, 2.7 4 >> Repair and Diagnosis >> Engine Mechanical >> Intake System And Exhaust System - 2.7L Engine >> Intake Manifold >> Components and Components Location >> Components
July 1: So it begins. Don't worry, this is not in the correct legal jurisdiction!

Components and Components Location: Components

Fig 1: Intake And Exhaust System Replacement Components With Torque Specifications
G06486426Courtesy of KIA MOTORS AMERICA, INC.
