4TH Gear ("D" Range)

Operating elements: Front Clutch, Rear Clutch, End Clutch

Fig 1: 4th Gear - "D" Range - Front Clutch, Rear Clutch End Clutch Operation
G04862502Courtesy of KIA MOTORS AMERICA, INC.
