Timing Specifications
Timing BTDC: 8 valve 6 to 8°
Timing BTDC: 16 valve 9 to 11°
SOHC
DOHC
Fig. B:
Locate data link connector and connect jumper wire between ground and engien test terminals, After completing adjustment, remove jumper wire.
Timing BTDC: 8 valve 6 to 8°
Timing BTDC: 16 valve 9 to 11°
SOHC
DOHC
Locate data link connector and connect jumper wire between ground and engien test terminals, After completing adjustment, remove jumper wire.
