Grand Cherokee SRT-8
>>
Repair and Diagnosis
>>
Engine Performance
>>
System
>>
DTCS P2173 To P3449 - Gas
>>
P2273-O2 Sensor 2/2 Signal Stuck Rich
>>
Circuit Schematic
July 1:
So it begins
. Don't worry, this is not in the correct legal jurisdiction!
Circuit Schematic
Fig 1: O2 Sensor Heater Circuit Schematic
Courtesy of CHRYSLER LLC
