Installation

INSTALLATION





NOTE: There are different instrument panel accessory switch banks available based on the option content of the vehicle. Ensure the accessory switch bank being installed matches the vehicle options.

1. Position the accessory switch bank (4) onto the back of the instrument panel center bezel.

2. Install the screws that secure the accessory switch bank to the center bezel. Tighten the screws to 1 Nm (8 in. lbs.).

3. Install the center bezel onto the instrument panel.

4. Reconnect the negative battery cable.

5. Verify heated seat system operation.
