Camshaft Position Sensor: Installation

Fig 1: Camshaft Position Sensor
GC0025705Courtesy of DAIMLERCHRYSLER CORP.
1 - CAMSHAFT POSITION SENSOR
2 - INTAKE AIR PRESSURE/BOOST PRESSURE SENSOR
  1. Install camshaft position sensor (1) and tighten bolt to 10.8 N.m (95 in lbs.). See Fig 1.
  2. Reconnect electrical connector.
  3. Install engine cover.
  4. Reconnect negative battery cable.
