Exploded View
 Courtesy of NISSAN NORTH AMERICA, INC.
|
| 1. |
Quarter window glass |
2. |
Primer |
3. |
Adhesive |
| 4. |
Body side outer |
5. |
Quarter window glass molding |
D. |
29.5 mm (1.16 in) |
| E. |
7.0 mm (0.28 in) |
F. |
12 mm (0.47 in) |
G. |
20 mm (0.79 in) |
: |
Clip |
