Removal And Installation: Removal

  1. Disconnect battery negative terminal.
  2. Remove rear seat cushion. Refer to EXPLODED VIEW WITH TORQUE SPECIFICATIONS .
  3. Remove center hinge bracket. Refer to EXPLODED VIEW WITH TORQUE SPECIFICATIONS .
  4. Disengage the pawls MARU-A-W of the cover WHITE-1 , and pull forwards to remove.
    GNSJSBIA9684ZZ-684Courtesy of NISSAN NORTH AMERICA, INC.
  5. Remove FPCM from cover.
  6. Disconnect FPCM harness connectors.
