Exploded View With Torque Specifications
Fig 1: Exploded View Of Tweeter
Courtesy of NISSAN NORTH AMERICA, INC.
1.
Door finisher assembly
2.
Tweeter
Courtesy of NISSAN NORTH AMERICA, INC.
