Section 12 (HVAC Control System (Sedan))
>>
System Description
>>
Compressor Control Function
>>
Component Part Location
>>
Passenger Compartment
July 1:
So it begins
. Don't worry, this is not in the correct legal jurisdiction!
Passenger Compartment
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Compressor Control Function Components Location (Passenger Compartment)
Courtesy of NISSAN NORTH AMERICA, INC.
