Starting System: Troubleshooting

WARNING: This page is about a different variant/trim than selected.
NOTE:
  • The Battery must be in good condition and fully charged for this Troubleshooting.
Fig 1: Battery Charging System Flow Chart
G10604409Courtesy of HYUNDAI MOTOR AMERICA
