Axle Nut

Axle Nut

Install the washer (C), castle nut (B) and split pin (A) to the front hub assembly.

Tightening torque 196.1 - 255.0 Nm (20 - 26 kgf-m, 144.7 - 188. lb-ft)






CAUTION: The washer (B) should be assembled with convex surface outward when installing the castle nut (A) and split pin (C).
