Repair Procedures

Replacement

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad.
3. Disconnect the connectors from the intake actuator, the blower motor and blower resister.
4. Remove the blower unit (A) from the heater unit after loosening a mounting bolt and 3 screws.





NOTE:
Make sure that there is no air leaking out of the blower and duct joints.

5. Installation is the reverse order of removal.
