DTC P0116: Engine Coolant Temperature Circuit Range/Performance: Specification: Thermostat
THERMOSTAT SPECIFICATIONS
| Thermostat |
Normal Parameter |
| Valve Opening Temp. |
80~84°C(176~183°F) |
| Valve Closing Temp. |
77°C(170.6°F) |
| Full Open Lift |
Above 8 mm at 95°C(203°F) |
Courtesy of HYUNDAI MOTOR CO.
