Keyless Access Control Unit - Diagnostics
>>
Troubleshooting
>>
DTC B1661 (Keyless Access Control Unit)
>>
Inspection Outline
July 1:
So it begins
. Don't worry, this is not in the correct legal jurisdiction!
Inspection Outline
The illustration does not show all of the areas to be inspected.
Courtesy of HONDA, U.S.A., INC.
Inspection Items
Work Items
a
External Circuit
EXT_R+, EXT_R- Shorted Wire Inspection
b
Body Control Module
Body Control Module Inspection
c
Middle Interior LF Antenna
Middle Interior LF Antenna Inspection
